670 Security Grille
Model 670
When your project calls for an upward coiling grille that is as versatile and attractive as it is rugged and secure, look no further than Model 670. These grilles provide an attractive yet functional means to secure areas where public access must be restricted, without blocking air, light or sight. A wide range of options make these grilles an ideal choice for interior or exterior use in a variety of retail, industrial and commercial settings.
Color Options
Powder Coat Color Options
PowderGuard Premium Powder Coat Options are Available in Approximately 200 Colors as Well as Custom Matching to Specification
Construction
Operation: Manual unless size requires chain hoist
Curtain Material/Finish: Aluminum, mill finish
Panel Width: Straight lattice (standard); staggered brick; straight with polycarbonate panels
Bottom Bar: Extruded aluminum, mill finish
Guide Type: Guide channels are extruded aluminum with continuous wear strips; mill finish;
Wall angles and any pack-out angles are galvanized steel
Mounting: Interior face of wall is standard
Between jamb options available
Brackets: Steel with black powdercoat finish
Pipe: Steel sized for maximum deflection of .03” per linear foot
Springs: Oil tempered, 20,000 cycle, torsion springs
Locking: Slide bolt for manual and crank operation; chain lock for chain hoist operation
Options
Operation: Electric operator, chain hoist, removable awning crank or crank box
Electric operator with automatic emergency egress; compliant with IBC 1008.1.4.4 & NFPA 101
Monitored Light Curtain (3' or 6' option)
Controls: Time clock, card reader, keypad access
Hood: Primed galvanized or stainless steel, mill finished or clear anodized aluminum
Fascia and back hoods: aluminum, stainless steel
Optional guide finishes: clear or bronze anodized, stainless steel
PowderGuard® premium powder coat paint finish in approximately 200 colors as well as custom matching to specification available on hood, curtain, bottom bar, guides, headplates
PowderGuard® Zinc and PowderGuard® Weathered finishes
Heavy usage package
Locking options include cylinder locks, slide bolts, security rods, interlocks
